Custom Lip-Seal Metal Die Components | Multi-Cavity Complex Structures

Modification from Prototype

1. ​Structural Variations:

   • Base Model: Multi-port cavities + lip-seal edge (critical mating surface)
   • Extended: Turbine blade molds/Microfluidic channels/Pressure-gradient flow paths

2. ​Material Enhancement:

   • Standard: S136 Tool Steel (mirror polish)
   • Advanced: Tungsten carbide coating/Ti-6Al-4V alloy/Copper-based thermal composite

3. ​Surface Engineering:

   • Nano-level polishing (surface roughness <20nm)
   • Micro-arc oxidation (enhanced wear resistance)
   • DLC coating (ultra-low friction verified)
